X SERIES RIGID-DECK ROLLER MOWERS
Get a professional finish year-round.The pristine cut offered by the RhinoAg X Series Roller Mowers is now more accessible than ever. Smaller cutting widths make the X603 and X804 ideal for more compact applications that still need the professional finish the X Series is known for.
With a versatile cutting height up to 5”, these rigid-deck roller mowers get the job done without fuss. The tempered steel blades pivot on high-tensile pivot bush assembly and there are no belts, making maintenance simple.
Features and Benefits
- 100% gear driven - no belts
- Reinforced 8-gauge Strenx® 700 MC structural steel deck
- Hardened, tempered spring steel blade carrier
- 3” x ¼” hardened, tempered, ground-edged parallel spring steel blades with 2 ½” overlap
- Sealed internal roller bearings for total protection against moisture, soil, and debris
- Galvanized finish for durability
- PTO Requirement of 50 - 60 HP
Who Should Buy
- Golf Courses
- Contractors
- Sod Farms
- Polo Clubs
- Commercial Mowing
- Universities
- Local Government
Download Literature
Warranty
Industry-leading toughness. Industry-leading warranty.Rhino products are built to take on whatever you can throw at them. But if something should break, you’ll be glad to know our warranties are just as strong. See your local Rhino dealer for complete details.
Full Machine Warranty
Year
Limited Driveline Warranty
Year
X Series Rigid Deck Roller Mower 3D Tour
Specifications
| X603 | X804 | |
| Cutting Width | 6' 3" | 8' |
| Transport Width | 6' 6" | 8' 2" |
| Overall Length | 4' 3" | |
| Cutting Height | Up to 5" | |
| Hitch | Lift-Type | |
| Blade Carrier | 3 1/4" x 3/8" spring steel, hardened and tempered | |
| No. of Blades | 6 | 8 |
| Blades | 3” x 1/4” spring steel ground edged parallel hardened and tempered, pivoting on high tensile pivot bush assembly | |
| Rotars | 3 | 4 |
| Mowing Rates | 5.3 acres/hr @7mph | 6.7 acres/hr @7mph |
| Blade Overlap | 2 1/2" | |
| PTO Horsepower Required (Min) | 50 HP | 50 HP |
| Tractor PTO | 540 RPM | |
| Output Shaft Diameter | 1 1/2" (40mm) | |
| Gearbox Oil | 85W-140 Factory Filled | |
| Blade Tip Speed | 14,764 FPM | |
| Drivelines | CAT 4 - 1 3/8” 6-spline | |
| Deck Thickness | 8 Guage Strenx® 700MC folded monocoque construction with reinforcement and underside trough is 8 guage Strenx® 700MC | |
| Weight | 1,047 lbs | 1,235 lbs |
